# Bundle Adjustment (BA) in vSLAM or SFM

[TOC]

## Overview

• BA is a key ingredient of Structure and Motion Estimation (SaM), almost always used as its last step

• It is an optimization problem over the 3D structure and viewing parameters (camera pose, intrinsic calibration, radial distortion parameters), which are simultaneously refined for minimizing reprojection error

• BA is the ML estimator assuming zero-mean Gaussian image noise

• BA boils down to a very large nonlinear least squares problem, typically solved with the Levenberg-Marquardt (LM) algorithm

Assume $$n$$ 3D points are seen in $$m$$ views with $$n = 4, m = 3$$.

Let $$\mathbf{x}_{ij}$$ be the projection of the $$i$$-th point on image $$j$$, $$\mathbf{a}_j$$ the vector of parameters for camera $$j$$ and $$\mathbf{b}_i$$ the vector of parameters for point $$i$$.

## BA as a NonLinear Least Squares Problem

BA minimizes the reprojection error over all point and camera parameters ($$v_{ij}$$ = 1 if point $$i$$ is visible in image $$j$$)

$\min_{\mathbf{a}_{j}, \mathbf{b}_{i}} \sum_{i=1}^{n} \sum_{j=1}^{m} v_{i j} d\left(\mathbf{Q}\left(\mathbf{a}_{j}, \mathbf{b}_{i}\right), \mathbf{x}_{i j}\right)^{2}$

The parameter vector (6m + 3n)

$\mathbf{P}= \left( \mathbf{a}_{1}^{T}, \mathbf{a}_{2}^{T}, \mathbf{a}_{3}^{T} \mid \mathbf{b}_{1}^{T}, \mathbf{b}_{2}^{T}, \mathbf{b}_{3}^{T}, \mathbf{b}_{4}^{T} \right)^{T}$

The measurement vector (2 * m * n)

$\mathbf{X}=\left(\mathbf{x}_{11}^{T}, \mathbf{x}_{12}^{T}, \mathbf{x}_{13}^{T}, \mathbf{x}_{21}^{T}, \mathbf{x}_{22}^{T}, \mathbf{x}_{23}^{T}, \mathbf{x}_{31}^{T}, \mathbf{x}_{32}^{T}, \mathbf{x}_{33}^{T}, \mathbf{x}_{41}^{T}, \mathbf{x}_{42}^{T}, \mathbf{x}_{43}^{T}\right)^{T}$

The estimated measurement vector (and do a first-order Taylor expansion)

\begin{aligned} \hat{\mathbf{X}} &= f(\mathbf{P} \oplus \Delta) = \left( \hat{\mathbf{x}}_{11}^{T}, \ldots, \hat{\mathbf{x}}_{1 m}^{T}, \hat{\mathbf{x}}_{21}^{T}, \ldots, \hat{\mathbf{x}}_{2 m}^{T}, \ldots, \hat{\mathbf{x}}_{n 1}^{T}, \ldots, \hat{\mathbf{x}}_{n m}^{T} \right)^{T} \\&= f(a \oplus \delta{a}, b \oplus \delta{b}) \approx f(\mathbf{P}) + \mathbf{A} \delta{a} + \mathbf{B} \delta{b} \end{aligned}

with

$\hat{\mathbf{x}}_{i j} = \mathbf{Q}\left(\mathbf{a}_{j}, \mathbf{b}_{i} \right)$

BA corresponds to minimizing the squared $$\Sigma_{\mathbf{X}}^{-1}$$-norm, which is a nonlinear least squares problem

$\epsilon^{T} \epsilon = \sum_{i=1}^{4} \sum_{j=1}^{3} \|\epsilon_{ij} \|^{2} = \|\mathbf{X}-\hat{\mathbf{X}}\|^{2}$

or

$\epsilon^{T} \Sigma_{X}^{-1} \epsilon = \| \mathbf{X} - \hat{\mathbf{X}} \|^2_{\Sigma_X}$

## Solved with LM

the augmented normal equation of the LM nonlinear least-squares algorithm

$\color{blue} { \left(\mathbf{J}^{T} \Sigma_{X}^{-1} \mathbf{J} + \mu \mathbf{I}\right) \delta= \mathbf{J}^{T} \Sigma_{X}^{-1} \epsilon }$

The LM updating vector

$\delta \triangleq \left(\delta_{\mathbf{a}}^{T}, \delta_{\mathbf{b}}^{T}\right)^{T} \triangleq \left(\delta_{\mathbf{a}_{1}}^{T}, \delta_{\mathbf{a}_{2}}^{T}, \delta_{\mathbf{a}_{3}}^{T}, \delta_{\mathbf{b}_{1}}^{T}, \delta_{\mathbf{b}_{2}}^{T}, \delta_{\mathbf{b}_{3}}^{T}, \delta_{\mathbf{b}_{4}}^{T}\right)^{T}$

The Jacobian Matrix $$\mathbf{J}$$ in block form

$\mathbf{J} = \frac{\partial \hat{\mathbf{X}}}{\partial \mathbf{P}} = \left[ \frac{\partial \hat{\mathbf{X}}}{\partial \mathbf{a}} \mid \frac{\partial \hat{\mathbf{X}}}{\partial \mathbf{b}} \right] = \left[ \mathbf{A} \mid \mathbf{B} \right]$

with

$\mathbf{A}_{i j} \triangleq \frac{\partial \hat{\mathbf{x}}_{i j}}{\partial \mathbf{a}_{k}} = \mathbf{0}, \forall j \neq k$

$\mathbf{B}_{i j} \triangleq \frac{\partial \hat{\mathbf{x}}_{i j}}{\partial \mathbf{b}_{k}} = \mathbf{0}, \forall i \neq k$

the Covariance Matrix $$\Sigma$$

$\Sigma_{\mathbf{X}} = \operatorname{diag}\left(\Sigma_{\mathbf{x}_{11}}, \Sigma_{\mathbf{x}_{12}}, \Sigma_{\mathbf{x}_{13}}, \Sigma_{\mathbf{x}_{21}}, \Sigma_{\mathbf{x}_{22}}, \Sigma_{\mathbf{x}_{23}}, \Sigma_{\mathbf{x}_{31}}, \Sigma_{\mathbf{x}_{32}}, \Sigma_{\mathbf{x}_{33}}, \Sigma_{\mathbf{x}_{41}}, \Sigma_{\mathbf{x}_{42}}, \Sigma_{\mathbf{x}_{43}}\right)$

the Hessian or Information Matrix $$\mathbf{H}$$, the left-hand side of above augmented normal equation

$\mathbf{J}^{T} \Sigma_{\mathbf{X}}^{-1} \mathbf{J} = \left(\begin{array}{ccccccc} \mathbf{U}_{1} & \mathbf{0} & \mathbf{0} & \mathbf{W}_{11} & \mathbf{W}_{21} & \mathbf{W}_{31} & \mathbf{W}_{41} \\ \mathbf{0} & \mathbf{U}_{2} & \mathbf{0} & \mathbf{W}_{12} & \mathbf{W}_{22} & \mathbf{W}_{32} & \mathbf{W}_{42} \\ \mathbf{0} & \mathbf{0} & \mathbf{U}_{3} & \mathbf{W}_{13} & \mathbf{W}_{23} & \mathbf{W}_{33} & \mathbf{W}_{43} \\ \mathbf{W}_{11}^{T} & \mathbf{W}_{12}^{T} & \mathbf{W}_{13}^{T} & \mathbf{V}_{1} & \mathbf{0} & \mathbf{0} & \mathbf{0} \\ \mathbf{W}_{21}^{T} & \mathbf{W}_{22}^{T} & \mathbf{W}_{23}^{T} & \mathbf{0} & \mathbf{V}_{2} & \mathbf{0} & \mathbf{0} \\ \mathbf{W}_{31}^{T} & \mathbf{W}_{32}^{T} & \mathbf{W}_{33}^{T} & \mathbf{0} & \mathbf{0} & \mathbf{V}_{3} & \mathbf{0} \\ \mathbf{W}_{41}^{T} & \mathbf{W}_{42}^{T} & \mathbf{W}_{43}^{T} & \mathbf{0} & \mathbf{0} & \mathbf{0} & \mathbf{V}_{4} \end{array}\right)$

with

\begin{aligned} \mathbf{U}_{j} & \equiv \sum_{i=1}^{4} \mathbf{A}_{i j}^{T} \Sigma_{\mathbf{x}_{i j}}^{-1} \mathbf{A}_{i j}, \\ \mathbf{V}_{i} & \equiv \sum_{j=1}^{3} \mathbf{B}_{i j}^{T} \Sigma_{\mathbf{x}_{i j}}^{-1} \mathbf{B}_{i j}, \\ \mathbf{W}_{i j} & \equiv \mathbf{A}_{i j}^{T} \Sigma_{\mathbf{x}_{i j}}^{-1} \mathbf{B}_{i j} \end{aligned}

the right-hand side of above augmented normal equation

$\mathbf{J}^{T} \Sigma_{\mathbf{X}}^{-1} \epsilon = \begin{bmatrix} \sum_{i=1}^{4}\left(\mathbf{A}_{i 1}^{T} \Sigma_{\mathbf{x}_{i} 1}^{-1} \epsilon_{i 1}\right) \\[5pt] \sum_{i=1}^{4}\left(\mathbf{A}_{i 2}^{T} \Sigma_{\mathbf{x}_{i} 2}^{-1} \epsilon_{i 2}\right) \\[5pt] \sum_{i=1}^{4}\left(\mathbf{A}_{i 3}^{T} \Sigma_{\mathbf{x}_{i} 3}^{-1} \epsilon_{i 3}\right) \\[5pt] \sum_{j=1}^{3}\left(\mathbf{B}_{1 j}^{T} \Sigma_{\mathbf{x}_{1 j}}^{-1} \epsilon_{1 j}\right) \\[5pt] \sum_{j=1}^{3}\left(\mathbf{B}_{2 j}^{T} \Sigma_{\mathbf{x}_{2 j}}^{-1} \epsilon_{2 j}\right) \\[5pt] \sum_{j=1}^{3}\left(\mathbf{B}_{3 j}^{T} \Sigma_{\mathbf{x}_{3 j}}^{-1} \epsilon_{3 j}\right) \\[5pt] \sum_{j=1}^{3}\left(\mathbf{B}_{4 j}^{T} \Sigma_{\mathbf{x}_{4 j}}^{-1} \epsilon_{4 j}\right) \end{bmatrix}$

we can get with all above equations

$\left(\begin{array}{ccc|cccc} \mathbf{U}_{1} & \mathbf{0} & \mathbf{0} & \mathbf{W}_{11} & \mathbf{W}_{21} & \mathbf{W}_{31} & \mathbf{W}_{41} \\ \mathbf{0} & \mathbf{U}_{2} & \mathbf{0} & \mathbf{W}_{12} & \mathbf{W}_{22} & \mathbf{W}_{32} & \mathbf{W}_{42} \\ \mathbf{0} & \mathbf{0} & \mathbf{U}_{3} & \mathbf{W}_{13} & \mathbf{W}_{23} & \mathbf{W}_{33} & \mathbf{W}_{43} \\ \hline \mathbf{W}_{11}^{T} & \mathbf{W}_{12}^{T} & \mathbf{W}_{13}^{T} & \mathbf{V}_{1} & \mathbf{0} & \mathbf{0} & \mathbf{0} \\ \mathbf{W}_{21}^{T} & \mathbf{W}_{22}^{T} & \mathbf{W}_{23}^{T} & \mathbf{0} & \mathbf{V}_{2} & \mathbf{0} & \mathbf{0} \\ \mathbf{W}_{31}^{T} & \mathbf{W}_{32}^{T} & \mathbf{W}_{33}^{T} & \mathbf{0} & \mathbf{0} & \mathbf{V}_{3} & \mathbf{0} \\ \mathbf{W}_{41}^{T} & \mathbf{W}_{42}^{T} & \mathbf{W}_{43}^{T} & \mathbf{0} & \mathbf{0} & \mathbf{0} & \mathbf{V}_{4} \end{array}\right) \left(\begin{array}{c} \delta_{\mathbf{a}_{1}} \\ \delta_{\mathbf{a}_{2}} \\ \delta_{\mathbf{a}_{3}} \\ \delta_{\mathbf{b}_{1}} \\ \delta_{\mathbf{b}_{2}} \\ \delta_{\mathbf{b}_{3}} \\ \delta_{\mathbf{b}_{4}} \end{array}\right)= \left(\begin{array}{c} \epsilon_{\mathbf{a}_{1}} \\ \epsilon_{\mathbf{a}_{2}} \\ \epsilon_{\mathbf{a}_{3}} \\ \epsilon_{\mathbf{b}_{1}} \\ \epsilon_{\mathbf{b}_{2}} \\ \epsilon_{\mathbf{b}_{3}} \\ \epsilon_{\mathbf{b}_{4}} \end{array}\right)$

or

$\left[\begin{array}{c|c} \mathbf{A}^{T} \mathbf{A} & \mathbf{A}^{T} \mathbf{B} \\ \hline \mathbf{B}^{T} \mathbf{A} & \mathbf{B}^{T} \mathbf{B} \end{array}\right]\left(\frac{\delta_{\mathbf{a}}}{\delta_{\mathbf{b}}}\right)=\left(\frac{\mathbf{A}^{T} \epsilon}{\mathbf{B}^{T} \epsilon}\right)$

### $$\mathbf{J}^T \mathbf{J}$$ sparsity pattern

Draw Hessian matrix sparsity pattern from BAL Problem (code):

## Solving the augmented normal equations

The augmented normal equations take the form

$\left(\begin{array}{cc} \mathbf{U}^{*} & \mathbf{W} \\ \mathbf{W}^{T} & \mathbf{V}^{*} \end{array}\right)\left(\begin{array}{l} \delta_{\mathbf{a}} \\ \delta_{\mathbf{b}} \end{array}\right)=\left(\begin{array}{c} \epsilon_{\mathbf{a}} \\ \epsilon_{\mathbf{b}} \end{array}\right)$

### Solve $$\delta \mathbf{a}$$ (Marginalize 3D Points)

Performing block Gaussian elimination in the lhs matrix, $$\delta \mathbf{a}$$ is determined with Cholesky from $$\mathbf{V}^{*}$$’s Schur complement:

$\left(\mathbf{U}^{*}-\mathbf{W} \mathbf{V}^{*-1} \mathbf{W}^{T}\right) \delta_{\mathbf{a}}=\epsilon_{\mathbf{a}}-\mathbf{W} \mathbf{V}^{*-1} \epsilon_{\mathbf{b}}$

with

$\mathbf{V}^{*-1}= \left(\begin{array}{ccc} \mathbf{V}_{1}^{*-1} & \mathbf{0} & \cdots \\ \mathbf{0} & \mathbf{V}_{2}^{*-1} & \cdots \\ \vdots & \vdots & \ddots \end{array}\right)$

Why solve for $$\delta \mathbf{a}$$ first? Typically $$m<<n$$.

### Solve $$\delta \mathbf{b}$$

$$\delta \mathbf{b}$$ can be computed by back substitution into

$\mathbf{V}^{*} \delta_{\mathbf{b}} = \epsilon_{\mathbf{b}}-\mathbf{W}^{T} \delta_{\mathbf{a}}$

### the Reduced Camera Matrix

$\mathbf{S} \equiv \mathbf{U}^{*}-\mathbf{W} \mathbf{V}^{*-1} \mathbf{W}^{T}$

• The lhs matrix $$\mathbf{S}$$ is referred to as the reduced camera matrix (RCM)

• Since not all scene points appear in all cameras, $$\mathbf{S}$$ is sparse. This is known as secondary structure.

• Dealing with the RCM
• Store as dense, decompose with ordinary linear algebra
• SBA: A software package for generic sparse bundle adjustment
• cvsba: an OpenCV wrapper for sba library
• Store as sparse, factorize with sparse direct solvers
• Store as sparse, use conjugate gradient methods
• Avoid storing altogether

## Reducing the cost of BA

• reducing BA’s size
• BA in a sliding time window (local BA)
• reducing frequency of invocation
• Solve the RCM fewer times: Dog-leg in place of LM

• Ceres-Solver
• G2O
• GTSAM

## Others

### Incremental BA

#### 基于贝叶斯推断的增量式BA

• iSAM (Incremental Smoothing and Mapping) is an optimization library for sparse nonlinear problems as encountered in simultaneous localization and mapping (SLAM), provides efficient algorithms for batch and incremental optimization, recovering the exact least-squares solution

• iSAM2

#### 基于增量更新舒尔补的增量式BA

• zju3dv/EIBA: Efficient Incremental BA, which is part of our RKD-SLAM

• baidu/ICE-BA: Incremental, Consistent and Efficient Bundle Adjustment for Visual-Inertial SLAM

• SLAM++

## References

• SBA: A software package for generic sparse bundle adjustment
• Bundle adjustment gone public (slides)
• 增强现实：原理、算法与应用
